ZONGBOU's aluminum foil lunch boxes offer durability with resistance to tearing or puncturing, ensuring secure food storage. They excel in heat retention, keeping food hot for extended periods. Versatile for sandwiches, salads, and hot dishes, they are lightweight and portable, ideal for work, school, or picnics.
Equipment Characteristics
• Adopts cantilevered rotatable integrated touch screen control structure: more flexible, safer and less space-consuming than the traditional mobile operator station.
• The touch screen can remotely monitor the running status of the equipment and update the program online.
• The lifting cylinder adopts SMC servo control.
• The working table plate adopts 8 sets of lifting balls: it can realize one worker to finish unloading and changing molds within 15 minutes.
Specification
| Model | ZBFC-63 |
| Nominal Force | 630KN |
| Main Motor Power | 11KW |
| Stroke Range | 150-300mm |
| Stamping Speed Range | 30-80times/min. |
| Table Plate Size | L1100xW920mm,2sets movable plate |
| Maximum Mold Size | L1200xW850xH450mm |
| Maximum Feed Width | 900mm |
| Maximum Aluminum Foil Roll Outer Diameter | 600-1500mm |
| Stacker Conveyor Size | L2000xW900mm |
| Minimum Stackable Size | 120x120mm |
| Product Stacking Dimensions | One lane:L500xW800xH350mm |
| Two lane: L500xW400xH350mm | |
| Three lane:L500xW250xH350mm | |
| Four lane: L500xW190xH350mm | |
| Machine Size | 7100x2500x3500mm |
| Machine Weight | 11,500KGS |
