Aluminum Foil Container Machine ZBFC-130
Aluminum Foil Container Machine ZBFC-130

Aluminum Foil Container Machine

Press lubrication adopts automatic circulation electric thin oil lubrication system: progressive lubrication oil distributor with lubrication fault detection switch ensures sufficient and even lubrication and avoids damage to the guide rail by running without oil.

Stroke Range 150-260mm
Stamping Speed Range 30-80times/min.
Maximum Mold size L1650xW850xH500mm
Share:
Equipment Characteristics

• Press lubrication adopts automatic circulation electric thin oil lubrication system: progressive lubrication oil distributor with lubrication fault detection switch ensures sufficient and even lubrication and avoids damage to the guide rail by running without oil.



• The press adopts cantilever type rotatable integrated touch screen control structure, the touch screen can remotely monitor the running status of the equipment and update the program online.



• Aluminum foil feeding adopts servo system: it can adapt to different thickness and width of aluminum foil material to complete the feeding quickly and more accurately, and the curve output torque makes the aluminum foil smooth and not shaking.



• Adopting H-type eight-face guide rail and excellent dynamic balance design, low vibration and low noise.



• Adopting highly sensitive and reliable Italian OMPI dry clutch and Japanese TACO duplex solenoid valve: to ensure the accuracy and safety of the press slide running and stopping in time.



Specification
Model ZBFC-130
Nominal Force 1300KN
Main Motor Power 18.5KW
Stroke Range 150-260mm
Stamping Speed Range 30-80times/min.
Table Plate Size L1700xW900mm,2sets movable plate
Maximum Mold Size L1650xW850xH500mm
Maximum Feed Width 1420mm
Maximum Aluminum Foil Roll Outer Diameter 600-1500mm
Stacker Conveyor Size L2000xW1500mm
Minimum Stackable Size 100x100mm
Product Stacking Dimensions Four lane: L600xW300xH350mm
Five lane: L600xW240xH350mm
Six lane: L600xW200xH350mm
Seven lane:L600xW170xH350mm
Machine Size 7030x2800x3730mm
Machine Weight 17,500KGS
